Connecting the AV Receiver
—Continued
With this hookup, you can use your satellite or cable receiver to listen to your favorite TV programs
via the AV receiver, useful if your TV has no audio outputs.
• With connection
, you can listen to and record audio from the video source and listen in Zone 2.
• To enjoy Dolby Digital and DTS, use connection
or
. (For recording, use
and
, or
and
.)
Connecting a Satellite, Cable, Set-top box, or Other Video Source
Connection
AV receiver
Signal flow
Video source
Picture quality
COMPONENT VIDEO IN 3
⇐
Component video output
Best
CBL/SAT IN S
⇐
S-Video output
Better
CBL/SAT IN V
⇐
Composite video output
Standard
CBL/SAT IN L/R
⇐
Analog audio L/R output
DIGITAL COAXIAL IN 3 (CBL/SAT)
⇐
Digital coaxial output
DIGITAL OPTICAL IN 1 (GAME/TV)
⇐
Digital optical output
Hint!
Step 1: Video Connection
Choose a video connection that matches the video source (
,
, or
)
, and then make the connection.
You must connect the AV receiver to your TV via the same type of connection.
A B
C
Step 2: Audio Connection
Choose an audio connection that matches the video source (
,
, or
), and then make the connection.
a
b
c
a
b
c
a
b
a
c
A
B
C
a
b
c
Y
COAXIAL
OUT
P
B
COMPONENT VIDEO OUT
P
R
S VIDEO
OUT
AUDIO
OUT
VIDEO
OUT
L
R
OPTICAL
OUT
b
c
A
B
C
B
a
C
Satellite, cable, set-top box, etc.
Connect one or the other
Connection
must be assigned (see page 49)
c
Connection
must be
assigned
(see
page 47)
A
