background image

121

Specifications

Amplifier Section

Video Section

Tuner Section

General

Video Inputs

Video Outputs

Audio Inputs

Audio Outputs

Control Terminal

Specifications and features are subject to change without
notice.

Rated Output Power (FTC)
All channels:

100 watts minimum continuous power
per channel, 8 ohm loads, 2 channels
driven from 20 Hz to 20 kHz, with a
maximum total harmonic distortion of
0.08%
115 watts minimum continuous power
per channel, 8 ohm loads, 2 channels
driven at 1 kHz, with a maximum total
harmonic distortion of 0.7%
125 watts minimum continuous power
per channel, 6 ohm loads, 2 channels
driven at 1 kHz with a maximum total
harmonic distortion of 0.1%

Rated Output Power (IEC)

7 ch

×

160 W at 6 ohms, 1 kHz, 1 ch

driven

Maximum Output Power (JEITA)

7 ch

×

175 W at 6 ohms, 1 kHz, 1 ch

driven

Dynamic Power

240 W + 240 W (3

Ω, Front)

210 W + 210 W (4

Ω, Front)

120 W + 120 W (8

Ω, Front)

THD (Total Harmonic Distortion)

0.08% (Power Rated)
0.08% (1 kHz, 1 W)

Damping Factor

60 (Front, 1 kHz, 8

Ω)

Input Sensitivity and Impedance

200 mV/47 k

Ω (LINE)

2.5 mV/47 k

Ω, (PHONO MM)

Phono Overload

70 mV (MM 1 kHz, 0.5%)

Output Level and Impedance

200 mV/470

Ω (REC OUT)

Frequency Response

5 Hz - 100 kHz/+1 dB - 3 dB (Direct mode)

Tone Control

±10 dB, 50 Hz (BASS)
±10 dB, 20 kHz (TREBLE)

Signal to Noise Ratio

106 dB (LINE, IHF-A)
80 dB (PHONO, IHF-A)

Speaker Impedance

4

Ω - or 6 Ω - 16 Ω

Input Sensitivity/Output Level and Impedance

1 Vp-p/75

Ω (Component and S-Video Y)

0.7 Vp-p/75

Ω (Component P

B

/C

B

, P

R

/C

R

)

0.28 Vp-p/75

Ω (S-Video C)

1 Vp-p/75

Ω (Composite)

Component Video Frequency Response

5 Hz - 50 MHz - 3 dB

FM Tuning Frequency Range

North American: 87.5 MHz - 107.9 MHz
Australian: 87.5 MHz - 108.0 MHz

AM Tuning Frequency Range

North American: 530 kHz - 1710 kHz
Australian: 522/530 kHz - 1611/1710 kHz

Preset Channel

40

Digital Tuner (North American models only):

XM, SIRIUS

Power Supply

North American: AC 120 V, 60 Hz
Australian: AC 220 - 240 V, 50/60 Hz

Power Consumption

North American: 6.2 A
Australian: 600 W

Dimensions (W

×

H

×

D)

435

Ч

172

Ч

391 mm

17-1/8"

Ч

6-3/4"

Ч

15-3/8"

Weight

13.0 kg (28.7 lbs.)

HDMI

IN1, IN2, IN3

Component

IN1, IN2, IN3

S-Video

DVD, VCR/DVR, CBL/SAT, GAME/TV,
AUX

Composite

DVD, VCR/DVR, CBL/SAT, GAME/TV,
AUX

HDMI

OUT

Component

OUT

S-Video

MONITOR OUT, VCR/DVR

Composite

MONITOR OUT, VCR/DVR

Digital Inputs

Optical: 2 (Rear), 1 (Front)
Coaxial: 3

Analog Inputs

DVD (MULTICHANNEL), VCR/DVR,
CBL/SAT, GAME/TV, AUX, TAPE, CD,
PHONO

Multichannel Inputs

7.1

Digital Outputs

O

ptical: 1

Analog Outputs

TAPE, VCR/DVR, ZONE2

Multichannel Pre

Outputs

7

Subwoofer Pre Output

1

Speaker Outputs

FL, FR, C, SL, SR, SBL, SBR,
ZONE2 (L/R)

Phones

1

MIC

Yes

RS232

1

IR Input/Output

2/1

12 V Trigger Out

A,B,C
