Detailed Product Descriptions
71
Figure 23. RS/6000 43P 7043 Model 260 - System Planar & I/O Board
Table 10. RS/6000 43P 7043 Model 260 - System Planar & I/O Board Components
Location
Description
Location
Description
J1
Operator panel power
connector
J2
Operator panel audio
connector
Memory
Cards
Processor
Card
Processor Card
(primary)
