Expansion Slots and Input/Output Connectors
Expansion Slots and Input/Output Connectors
The following illustration shows the expansion slots and the
input/output connectors (ports) on the rear of the server.
Keyboard Connector
Mouse Connector
Serial Connector
(Com 2)
Serial Connector
(Com 1)
Video Connector
Parallel Connector
PCI Expansion
Slots
EISA Expansion
Slots
Power Connectors
10
PC Server 704 User's Handbook
