Removing Internal Drives
To remove a drive from the hot-swap bays, do the following steps:
1. Find the defective drive that you plan to remove.
2. Ensure that you have selected the correct drive for removal by
verifying that the amber indicator light above the drive is
illuminated.
3. Grasp the plastic lever on the drive carrier and pull the lever
toward you.
4. Remove the drive carrier 2 from the bay 1 and place it on a
static-protective surface.
1 2
5. If you are not installing or removing another hot-swap drive,
continue with the next step.
6. Go to Table 12 on page 286 and update the drive information;
then, return here.
7. Remove the drive from the carrier:
a. Remove the four screws that hold the drive to the carrier.
Save the screws for later use.
