Initialize Controller
73
Initialize Controller
This command allows the host to specify global configuration parameters, and initializes the controller for use within
a particular system. Configurable parameters include the number of CQE entries, global DMA control parameters, and
possible offboard locations for posting back returned commands. In addition, this command can be used to associate
station addresses with each of the attached ports. The MAC Control IOPB may be used to control particular ports on
the controller. The actual Initialize Controller IOPB points to a table containing the actual initialization values, named
the Controller Initialization Block.
This command must be issued through the Master Command Entry.
Table 3-19. Initialize Controller
Command Code
This field must be set to 0x41 to execute the Initialize Controller command.
Controller Initialization Block Offset
This field contains the offset from the start of Short I/O to the beginning of the Controller Initialization Block, in bytes.
Initialize Controller
Offst 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
0x00 Command Code
0x01 Command Options
0x02 Return Status
0x03 Normal Completion Level Normal Completion Vector
0x04 Error Completion Level Error Completion Vector
0x05
0x06 Reserved
(4 Bytes)
0x07 Controller Initialization Block Offset
0x08
to
0x11 Reserved
(20 Bytes)
