4221 Condor Hardware Installation Procedures
27
Table 2-11. Primary Base Address For 256 Byte Short I/O (Continued)
NOTE: 0 = IN (Logical 0), F = OUT (Logical 1)
ADDRESS J19 PIN SETTINGS J20, J21, J22 PIN SETTINGS
15-16 13-14 11-12 9-10 7-8 5-6 3-4 1-2 J13 J14 J15
2800 0 0 0 F 0 F 0 0 0 0 0
2900 F 0 0 F 0 F 0 0 0 0 0
2A00 0 F 0 F 0 F 0 0 0 0 0
2B00 F F 0 F 0 F 0 0 0 0 0
2C00 0 0 F F 0 F 0 0 0 0 0
2D00 F 0 F F 0 F 0 0 0 0 0
2E00 0 F F F 0 F 0 0 0 0 0
2F00 F F F F 0 F 0 0 0 0 0
3000 0 0 0 0 F F 0 0 0 0 0
3100 F 0 0 0 F F 0 0 0 0 0
3200 0 F 0 0 F F 0 0 0 0 0
3300 F F 0 0 F F 0 0 0 0 0
3400 0 0 F 0 F F 0 0 0 0 0
3500 F 0 F 0 F F 0 0 0 0 0
3600 0 F F 0 F F 0 0 0 0 0
3700 F F F 0 F F 0 0 0 0 0
3800 0 0 0 F F F 0 0 0 0 0
3900 F 0 0 F F F 0 0 0 0 0
3A00 0 F 0 F F F 0 0 0 0 0
3B00 F F 0 F F F 0 0 0 0 0
3C00 0 0 F F F F 0 0 0 0 0
3D00 F 0 F F F F 0 0 0 0 0
3E00 0 F F F F F 0 0 0 0 0
3F00 F F F F F F 0 0 0 0 0
4000 0 0 0 0 0 0 F 0 0 0 0
4100 F 0 0 0 0 0 F 0 0 0 0
4200 0 F 0 0 0 0 F 0 0 0 0
4300 F F 0 0 0 0 F 0 0 0 0
4400 0 0 F 0 0 0 F 0 0 0 0
4500 F 0 F 0 0 0 F 0 0 0 0
4600 0 F F 0 0 0 F 0 0 0 0
4700 F F F 0 0 0 F 0 0 0 0
4800 0 0 0 F 0 0 F 0 0 0 0
4900 F 0 0 F 0 0 F 0 0 0 0
4A00 0 F 0 F 0 0 F 0 0 0 0
4B00 F F 0 F 0 0 F 0 0 0 0
4C00 0 0 F F 0 0 F 0 0 0 0
4D00 F 0 F F 0 0 F 0 0 0 0
4E00 0 F F F 0 0 F 0 0 0 0
4F00 F F F F 0 0 F 0 0 0 0
