APPENDIX A
SPECIFICATIONS
VMEbus Specifications
DTB Master
A16, A24, A32, D08 (EO), D16, D32: BLT, D64: BLT
DTB Slave
A16, D08 (EO), D16, D32
Requester
Any of R(0-3), Static RWD, ROR
Interrupter
Any of I(1-7), Dynamic D08 (O)
Power Requirements
Dual AUI Ethernet Motherboard
5.70A typical @ +5V DC (+/- 5%)
6.20A maximum @ +5V DC (+/- 5%)
7mA maximum @ +12V DC (+/- 5%) See note.
30mA maximum @ -12V DC (+/- 5%)
Dual 10BaseT Ethernet Motherboard
5.70A typical @ +5V DC (+/- 5%)
6.20A maximum @ +5V DC (+/- 5%)
7mA maximum @ +12V DC (+/- 5%) See note.
30mA maximum @ -12V DC (+/- 5%)
Dual AUI Daughter Card
0.80A typical @ +5V DC (+/- 5%)
0.60A maximum @ +5V DC (+/- 5%)
0.00A maximum @ +12V DC (+/- 5%) See note.
DUAL 10BaseT Daughter Card
0.80A typical @ +5V DC (+/- 5%)
0.60A maximum @ +5V DC (+/- 5%)
0.00A maximum @ +12V DC (+/- 5%) See note.
Single Channel Ethernet Daughter Card
0.70A typical @ +5V DC (+/- 5%)
0.50A maximum @ +5V DC (+/- 5%)
0.00A maximum @ +12V DC (+/- 5%) See note.
NOTE
Each Condor AUI port provides +12 volts at the cable connector
(DB15). An additional.5 amps (maximum) of +12 volts may be required
for each AUI transceiver (or box) connected to the Condor.
