4221 Condor Hardware Installation Procedures
17
J9 +12 VOLTS Flash Programming Protect:
IN: +12 Volt power connected to EPROM socket.
OUT: +12 Volt power disconnected from EPROM socket.
J12 VME Bus Grant:
Pins 1 - 12 Reserved
Pins 13 - 16 VME Bus Grant:
Table 2-5. VME Bus Grant Settings
* = Factory Default
J13 Firmware Option Jumpers:
(Pins 1-2) Reserved
(Pins 3-4) Memory Test Enable
IN = Disable
OUT = Enable
BUS GRANT
PIN #
13-14 15-16
0 IN IN
1 IN OUT
2 OUT IN
*3 *OUT *OUT
J9
J9
(PB04221-000) (PB04221-001)
16
15
2
1
J12
8
7
2
1
J13
