Chapter 2 - Hardware Installation
16
Table 2-4. Run Mode LED Matrix
Step 3. Set Onboard Motherboard Jumpers
Set all onboard jumpers so that the Condor is properly configured for operation within your system. The board layout
as illustrated in figure 2-1 shows the location of the jumpers.
Motherboard Jumper Settings
The following are jumpers and the default settings used on the Condor motherboard. IN refers to the jumper
being installed across the pins indicated, OUT indicates the jumper is removed.
CAUTION!
Jumpers J1 through J4, J6 through J8, J10 and J11 are used for manufacturing
options. If populated, they are configured to factory default settings. These jumpers
must not be altered.
J5 FLASH0
IN: FLASH logic enabled.
OUT: FLASH logic disabled.
LED1 LED2 LED3 LED4 Function
ON OFF OFF OFF 1-4 Commands On Board
ON ON OFF OFF 5-16 Commands On Board
ON ON ON OFF 17-64 Commands On Board
ON ON ON ON 65 or More Commands On Board
J5
