4221 Condor Hardware Installation Procedures
37
Table 2-14. Secondary Base Address For 512 Byte Short I/O
NOTE: 0 = IN (Logical 0), F = OUT (Logical 1)
ADDRESS J23 PIN SETTINGS J24, J25, J26 PIN SETTINGS
15-16 13-14 11-12 9-10 7-8 5-6 3-4 1-2 J24 J25 J26
0000 F 0 0 0 0 0 0 0 F 0 0
0200 F F 0 0 0 0 0 0 F 0 0
0400 F 0 F 0 0 0 0 0 F 0 0
0600 F F F 0 0 0 0 0 F 0 0
0800 F 0 0 F 0 0 0 0 F 0 0
0A00 F F 0 F 0 0 0 0 F 0 0
0C00 F 0 F F 0 0 0 0 F 0 0
0E00 F F F F 0 0 0 0 F 0 0
1000 F 0 0 0 F 0 0 0 F 0 0
1200 F F 0 0 F 0 0 0 F 0 0
1400 F 0 F 0 F 0 0 0 F 0 0
1600 F F F 0 F 0 0 0 F 0 0
1800 F 0 0 F F 0 0 0 F 0 0
1A00 F F 0 F F 0 0 0 F 0 0
1C00 F 0 F F F 0 0 0 F 0 0
1E00 F F F F F 0 0 0 F 0 0
2000 F 0 0 0 0 F 0 0 F 0 0
2200 F F 0 0 0 F 0 0 F 0 0
2400 F 0 F 0 0 F 0 0 F 0 0
2600 F F F 0 0 F 0 0 F 0 0
2800 F 0 0 F 0 F 0 0 F 0 0
2A00 F F 0 F 0 F 0 0 F 0 0
2C00 F 0 F F 0 F 0 0 F 0 0
2E00 F F F F 0 F 0 0 F 0 0
3000 F 0 0 0 F F 0 0 F 0 0
3200 F F 0 0 F F 0 0 F 0 0
3400 F 0 F 0 F F 0 0 F 0 0
3600 F F F 0 F F 0 0 F 0 0
3800 F 0 0 F F F 0 0 F 0 0
3A00 F F 0 F F F 0 0 F 0 0
3C00 F 0 F F F F 0 0 F 0 0
3E00 F F F F F F 0 0 F 0 0
4000 F 0 0 0 0 0 F 0 F 0 0
4200 F F 0 0 0 0 F 0 F 0 0
4400 F 0 F 0 0 0 F 0 F 0 0
4600 F F F 0 0 0 F 0 F 0 0
4800 F 0 0 F 0 0 F 0 F 0 0
4A00 F F 0 F 0 0 F 0 F 0 0
4C00 F 0 F F 0 0 F 0 F 0 0
4E00 F F F F 0 0 F 0 F 0 0
