Chapter 2 - Hardware Installation
24
Table 2-10. Primary Base Address For 512 Byte Short I/O
NOTE: 0 = IN (Logical 0), F = OUT (Logical 1)
ADDRESS
J19 PIN SETTINGS
J20, J21, J22 PIN SETTINGS
15-16
13-14
11-12
9-10
7-8
5-6
3-4
1-2
J20
J21
J22
C000
F
0
0
0
0
0
F
F
F
0
0
C200
F
F
0
0
0
0
F
F
F
0
0
C400
F
0
F
0
0
0
F
F
F
0
0
C600
F
F
F
0
0
0
F
F
F
0
0
C800
F
0
0
F
0
0
F
F
F
0
0
CA00
F
F
0
F
0
0
F
F
F
0
0
CC00
F
0
F
F
0
0
F
F
F
0
0
CE00
F
F
F
F
0
0
F
F
F
0
0
D000
F
0
0
0
F
0
F
F
F
0
0
D200
F
F
0
0
F
0
F
F
F
0
0
D400
F
0
F
0
F
0
F
F
F
0
0
D600
F
F
F
0
F
0
F
F
F
0
0
D800
F
0
0
F
F
0
F
F
F
0
0
DA00
F
F
0
F
F
0
F
F
F
0
0
DC00
F
0
F
F
F
0
F
F
F
0
0
DE00
F
F
F
F
F
0
F
F
F
0
0
E000
F
0
0
0
0
F
F
F
F
0
0
E200
F
F
0
0
0
F
F
F
F
0
0
E400
F
0
F
0
0
F
F
F
F
0
0
E600
F
F
F
0
0
F
F
F
F
0
0
E800
F
0
0
F
0
F
F
F
F
0
0
EA00
F
F
0
F
0
F
F
F
F
0
0
EC00
F
0
F
F
0
F
F
F
F
0
0
EE00
F
F
F
F
0
F
F
F
F
0
0
F000
F
0
0
0
F
F
F
F
F
0
0
F200
F
F
0
0
F
F
F
F
F
0
0
F400
F
0
F
0
F
F
F
F
F
0
0
F600
F
F
F
0
F
F
F
F
F
0
0
F800
F
0
0
F
F
F
F
F
F
0
0
FA00
F
F
0
F
F
F
F
F
F
0
0
FC00
F
0
F
F
F
F
F
F
F
0
0
FE00
F
F
F
F
F
F
F
F
F
0
0
