Chapter 2 - Hardware Installation
26
Table 2-11. Primary Base Address For 256 Byte Short I/O
NOTE: 0 = IN (Logical 0), F = OUT (Logical 1)
ADDRESS J19 PIN SETTINGS J20, J21, J22 PIN SETTINGS
15-16 13-14 11-12 9-10 7-8 5-6 3-4 1-2 J20 J21 J22
0000 0 0 0 0 0 0 0 0 0 0 0
0100 F 0 0 0 0 0 0 0 0 0 0
0200 0 F 0 0 0 0 0 0 0 0 0
0300 F F 0 0 0 0 0 0 0 0 0
0400 0 0 F 0 0 0 0 0 0 0 0
0500 F 0 F 0 0 0 0 0 0 0 0
0600 0 F F 0 0 0 0 0 0 0 0
0700 F F F 0 0 0 0 0 0 0 0
0800 0 0 0 F 0 0 0 0 0 0 0
0900 F 0 0 F 0 0 0 0 0 0 0
0A00 0 F 0 F 0 0 0 0 0 0 0
0B00 F F 0 F 0 0 0 0 0 0 0
0C00 0 0 F F 0 0 0 0 0 0 0
0D00 F 0 F F 0 0 0 0 0 0 0
0E00 0 F F F 0 0 0 0 0 0 0
0F00 F F F F 0 0 0 0 0 0 0
1000 0 0 0 0 F 0 0 0 0 0 0
1100 F 0 0 0 F 0 0 0 0 0 0
1200 0 F 0 0 F 0 0 0 0 0 0
1300 F F 0 0 F 0 0 0 0 0 0
1400 0 0 F 0 F 0 0 0 0 0 0
1500 F 0 F 0 F 0 0 0 0 0 0
1600 0 F F 0 F 0 0 0 0 0 0
1700 F F F 0 F 0 0 0 0 0 0
1800 0 0 0 F F 0 0 0 0 0 0
1900 F 0 0 F F 0 0 0 0 0 0
1A00 0 F 0 F F 0 0 0 0 0 0
1B00 F F 0 F F 0 0 0 0 0 0
1C00 0 0 F F F 0 0 0 0 0 0
1D00 F 0 F F F 0 0 0 0 0 0
1E00 0 F F F F 0 0 0 0 0 0
1F00 F F F F F 0 0 0 0 0 0
2000 0 0 0 0 0 F 0 0 0 0 0
2100 F 0 0 0 0 F 0 0 0 0 0
2200 0 F 0 0 0 F 0 0 0 0 0
2300 F F 0 0 0 F 0 0 0 0 0
2400 0 0 F 0 0 F 0 0 0 0 0
2500 F 0 F 0 0 F 0 0 0 0 0
2600 0 F F 0 0 F 0 0 0 0 0
2700 F F F 0 0 F 0 0 0 0 0
