System Interface
This section defines how the host communicates with the controller. The shared memory interface is defined, and each
major section described in detail. Full definitions for particular commands (what is communicated) can be found in
a following section.
MACSI Organization
Ethernet MACSI for the Condor consists of eight major sections, as illustrated in the following memory map:
Table 3-1. MACSI Memory Map
The Master Control/Status Block (MCSB) is used to pass and receive information relating to the overall functioning of
the controller.
MACSI Memory Map
Addr 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
0x000
to
0x00F Master Control Status Block
(16 Bytes)
0x010
to
0x01B Master Command Queue Entry
(12 Bytes)
0x01C
to
0xXXX Command Queue Entries
(12 Bytes * N)
0xXXX
to
0x72F Onboard IOPBs (optional)
(1812 - 12N Bytes)
0x730
to
0x73F Command Response Block
(16 Bytes)
0x740
to
0x763 Returned IOPB / Multiple Completion Return
(36 Bytes)
0x764
to
0x7AB Configuration Status Block / Multiple Completion Return
(72 Bytes)
0x7AC
to
0x7FF Controller Statistics Block / Multiple Completion Return
(84 Bytes)
