4221 Condor Hardware Installation Procedures
29
Table 2-11. Primary Base Address For 256 Byte Short I/O (Continued)
NOTE: 0 = IN (Logical 0), F = OUT (Logical 1)
ADDRESS J19 PIN SETTINGS J20, J21, J22 PIN SETTINGS
15-16 13-14 11-12 9-10 7-8 5-6 3-4 1-2 J20 J21 J22
7800 0 0 0 F F F F 0 0 0 0
7900 F 0 0 F F F F 0 0 0 0
7A00 0 F 0 F F F F 0 0 0 0
7B00 F F 0 F F F F 0 0 0 0
7C00 0 0 F F F F F 0 0 0 0
7D00 F 0 F F F F F 0 0 0 0
7E00 0 F F F F F F 0 0 0 0
7F00 F F F F F F F 0 0 0 0
8000 0 0 0 0 0 0 0 F 0 0 0
8100 F 0 0 0 0 0 0 F 0 0 0
8200 0 F 0 0 0 0 0 F 0 0 0
8300 F F 0 0 0 0 0 F 0 0 0
8400 0 0 F 0 0 0 0 F 0 0 0
8500 F 0 F 0 0 0 0 F 0 0 0
8600 0 F F 0 0 0 0 F 0 0 0
8700 F F F 0 0 0 0 F 0 0 0
8800 0 0 0 F 0 0 0 F 0 0 0
8900 F 0 0 F 0 0 0 F 0 0 0
8A00 0 F 0 F 0 0 0 F 0 0 0
8B00 F F 0 F 0 0 0 F 0 0 0
8C00 0 0 F F 0 0 0 F 0 0 0
8D00 F 0 F F 0 0 0 F 0 0 0
8E00 0 F F F 0 0 0 F 0 0 0
8F00 F F F F 0 0 0 F 0 0 0
9000 0 0 0 0 F 0 0 F 0 0 0
9100 F 0 0 0 F 0 0 F 0 0 0
9200 0 F 0 0 F 0 0 F 0 0 0
9300 F F 0 0 F 0 0 F 0 0 0
9400 0 0 F 0 F 0 0 F 0 0 0
9500 F 0 F 0 F 0 0 F 0 0 0
9600 0 F F 0 F 0 0 F 0 0 0
9700 F F F 0 F 0 0 F 0 0 0
9800 0 0 0 F F 0 0 F 0 0 0
9900 F 0 0 F F 0 0 F 0 0 0
9A00 0 F 0 F F 0 0 F 0 0 0
9B00 F F 0 F F 0 0 F 0 0 0
9C00 0 0 F F F 0 0 F 0 0 0
9D00 F 0 F F F 0 0 F 0 0 0
9E00 0 F F F F 0 0 F 0 0 0
9F00 F F F F F 0 0 F 0 0 0
