4221 Condor Hardware Installation Procedures
45
Table 2-15. Secondary Base Address For 256 Byte Short I/O (Continued)
NOTE: 0 = IN (Logical 0), F = OUT (Logical 1)
ADDRESS J23 PIN SETTINGS J24, J25, J26 PIN SETTINGS
15-16 13-14 11-12 9-10 7-8 5-6 3-4 1-2 J24 J25 J26
A000 0 0 0 0 0 F 0 F 0 0 0
A100 F 0 0 0 0 F 0 F 0 0 0
A200 0 F 0 0 0 F 0 F 0 0 0
A300 F F 0 0 0 F 0 F 0 0 0
A400 0 0 F 0 0 F 0 F 0 0 0
A500 F 0 F 0 0 F 0 F 0 0 0
A600 0 F F 0 0 F 0 F 0 0 0
A700 F F F 0 0 F 0 F 0 0 0
A800 0 0 0 F 0 F 0 F 0 0 0
A900 F 0 0 F 0 F 0 F 0 0 0
AA00 0 F 0 F 0 F 0 F 0 0 0
AB00 F F 0 F 0 F 0 F 0 0 0
AC00 0 0 F F 0 F 0 F 0 0 0
AD00 F 0 F F 0 F 0 F 0 0 0
AE00 0 F F F 0 F 0 F 0 0 0
AF00 F F F F 0 F 0 F 0 0 0
B000 0 0 0 0 F F 0 F 0 0 0
B100 F 0 0 0 F F 0 F 0 0 0
B200 0 F 0 0 F F 0 F 0 0 0
B300 F F 0 0 F F 0 F 0 0 0
B400 0 0 F 0 F F 0 F 0 0 0
B500 F 0 F 0 F F 0 F 0 0 0
B600 0 F F 0 F F 0 F 0 0 0
B700 F F F 0 F F 0 F 0 0 0
B800 0 0 0 F F F 0 F 0 0 0
B900 F 0 0 F F F 0 F 0 0 0
BA00 0 F 0 F F F 0 F 0 0 0
BB00 F F 0 F F F 0 F 0 0 0
BC00 0 0 F F F F 0 F 0 0 0
BD00 F 0 F F F F 0 F 0 0 0
BE00 0 F F F F F 0 F 0 0 0
BF00 F F F F F F 0 F 0 0 0
C000 0 0 0 0 0 0 F F 0 0 0
C100 F 0 0 0 0 0 F F 0 0 0
C200 0 F 0 0 0 0 F F 0 0 0
C300 F F 0 0 0 0 F F 0 0 0
C400 0 0 F 0 0 0 F F 0 0 0
C500 F 0 F 0 0 0 F F 0 0 0
C600 0 F F 0 0 0 F F 0 0 0
C700 F F F 0 0 0 F F 0 0 0
