Page 112: Fuse, Reliability

100
Appendix A
Mechanical (Nominal)
Length
233 mm
Width
160 mm
Thickness
20 mm
Weight
.45 Kg
Operating Environment
Temperature
0-55 degrees Centigrade
Relative Humidity
10% - 90% Noncondensing
Air Flow
250 CFM Minimum
Fuse
The AUI version of the Condor has a 1.5 amp fuse (F1) used to protect the +12 volts power when provided by the
Condor. LITTLEFUSE part number is PN 273-01.5. To determine the location of the fuse on the board, refer to the
appropriate board layout.
Reliability
MTBF per Bellcore Standard
209,697 hours
