This menu is used to set the communication settings between
this unit and the external device connected.

RS-232C Setting

This item is used to remotely control this unit via a PC
connected to the RS-232C terminal.

COM/LAN

1 RS-232C Setting

System Menu

step

1. Select the communication mode.

Remote A: Controls this unit via a PC and this unit
returns every status information.

Remote B: Controls this unit via a PC and this unit
returns only the response to the command code.

Remote C: Controls this unit via a PC and this unit
returns nothing.

Off: Does not control this unit via a PC.

step

2. Set the port settings shown below.

• Transmission mode

• Data bit length

• Parity bit

• Stop bit length

• Delimiter

Set all the settings to the same values as the PC

connected.

COM/LAN

System Menu

RS-485 Setting

This item is used to make the settings to use this unit with
optional keyboard connected to RS-485 terminal.

COM/LAN

2 RS-485 Setting

System Menu

step

1. Select the recorder address.

Standalone: Does not use the optional keyboard
with this unit.

Slave ID:01 to 16: Sets the ID number of this unit
when using with optional keyboard.
