30
Setup Menu
Menu chart (continued)
1 Set Recording Pattern A (Normal/Timer) 211 000 000
1 Camera Check 211 100 000
2 Auto + D Set > 211 2AD 000
D Execute 211 2AD D00
2 Easy + D Set > 211 2ED 000
D Execute 211 2ED D00
2 Manual + D Set > 211 2MD 000
D View > 211 2MD D00
3 Alarm Recording Menu 211 300 000
1 Easy + D Set > 211 3ED 000
D Execute 211 3ED D00
1 Manual + D Set > 211 3MD 000
D View > 211 3MD D00
4 Alarm Camera Setting 211 400 000
D View > 211 4D0 000
D Next > 211 4DD 000
5 Alarm Trigger In/Out 211 500 000
D View > 211 5D0 000
Specifies the recording setting for recording pattern A.
Selects the camera number to be recorded.
Sets the normal recording setting automatically by
specifying the recording cycle and the recording hour a day.
Shows the preview of the normal recording settings.
Specifies frame or field, recording rate, and picture grade of
normal recording to the same settings for all the camera
numbers.
Shows the preview of the normal recording settings.
Specifies frame or field, recording rate, and picture grade of
normal recording for each camera number individually.
Shows the preview of the normal recording settings.
Specifies the alarm recording settings.
Specifies frame or field, recording rate, and picture grade of
alarm recording to the same settings for all the camera
numbers.
Shows the preview of the alarm recording settings.
Specifies frame or field, recording rate, and picture grade of
alarm recording for each camera number individually.
Shows the preview of the alarm recording settings.
Specifies the sensor settings for alarm recording.
Shows the recording camera for each sensor.
Shows the recording camera for each sensor.
Specifies the trigger and PTZ camera preset settings for
alarm recording.
Shows the preview of the trigger and PTZ camera preset
settings for alarm recording.
49-51,110,111
49-51
49-51, 110
49-51
49-51, 110
49-51
49-51, 110
49-51
49-51,110,111
49-51, 110
49-51
49-51, 110
49-51
49-51, 111
49-51
49-51
49-51, 111
49-51
Menu Menu Address Functions Pages
1
Recording
Setup Menu (200 000 000)
