Electrical System
Section 6
6-36
Part No. 80-1214-3
Wiring Diagrams
The following pages contain electrical wiring diagrams. Be sure you are referring to the correct diagram for the ice
machine which you are servicing.
WIRING DIAGRAM LEGEND
The following symbols are used on all of the wiring diagrams:
*
Internal Compressor Overload
(Some models have external compressor overloads)
( )
Wire Number Designation
(The number is marked at each end of the wire)
—>>—
Multi-Pin Connection
(Electrical Box Side) —>>— (Compressor Compartment Side)
!
Warning
Always disconnect power before working on
electrical circuitry.
Revised 8/2003
