4.1 Parameter List
PARAMETERS
18
PARAMETER
Func-
tion
Parameter
Number
Name Setting Range
Minimum
Setting
Increments
Factory Setting
Refer To
Page:
0 Torque boost (Note 1) 0 to 30% 0.1% 1% 48
1 Maximum frequency 0 to 60Hz 0.01Hz 60Hz 49
2 Minimum frequency 0 to 120Hz 0.01Hz 0Hz 49
3 Base frequency 0 to 400Hz 0.01Hz 60Hz<50Hz> 50
4 Multi-speed setting (high speed) 0 to 400Hz 0.01Hz 60Hz 51
5 Multi-speed setting (middle speed) 0 to 400Hz 0.01Hz 30Hz 51
6 Multi-speed setting (low speed) 0 to 400Hz 0.01Hz 10Hz 51
7 Acceleration time
0 to 3600 sec/
0 to 360 sec
0.1 sec/
0.01 sec
15 sec 52
8 Deceleration time
0 to 3600 sec/
0 to 360 sec
0.1 sec/
0.01 sec
15 sec 52
B
asi
c fu
ncti
on
s
9 Electronic thermal O/L relay 0 to 3600A 0.1A
Rated output cur-
rent
52
10 DC injection brake operation frequency 0 to 120Hz, 9999 0.01Hz 3Hz 54
11 DC injection brake operation time 0 to 10 sec, 8888 0.1 sec 0.5 sec 54
12 DC injection brake voltage 0 to 30% 0.1% 1% 54
13 Starting frequency 0 to 60Hz 0.01Hz 0.5Hz 55
14 Load pattern selection (Note 1) 0 to 5 1 0 55
15 Jog frequency 0 to 400Hz 0.01Hz 5Hz 56
16 Jog acceleration/deceleration time
0 to 3600 sec/
0 to 360 sec
0.1 sec/
0.01 sec
0.5 sec 56
17 MRS input selection 0,2 1 0 57
18 High-speed maximum frequency 0 to 400Hz 0.01Hz 60Hz 57
19 Base frequency voltage (Note 1) 0 to 1000V, 8888, 9999 0.1V 9999<8888> 57
20
Acceleration/deceleration reference
frequency
1 to 400Hz 0.01Hz 60Hz<50Hz> 57
21
Acceleration/deceleration time
increments
0,1 1 0 57
*22 Stall prevention operation level 0 to 150%, 9999 0.1% 150% 58
*23
Stall prevention operation level at double
speed
0 to 150%, 9999 0.1% 9999 58
24 Multi-speed setting (speed 4) 0 to 400Hz, 9999 0.01Hz 9999 59
25 Multi-speed setting (speed 5) 0 to 400Hz, 9999 0.01Hz 9999 59
26 Multi-speed setting (speed 6) 0 to 400Hz, 9999 0.01Hz 9999 59
27 Multi-speed setting (speed 7) 0 to 400Hz, 9999 0.01Hz 9999 59
28 Multi-speed input compensation 0, 1 1 0 59
29 Acceleration/deceleration pattern 0, 1, 2, 3 1 0 60
30 Regenerative function selection 0, 1, 2 1 0 61
31 Frequency jump 1A 0 to 400Hz, 9999 0.01Hz 9999 62
32 Frequency jump 1B 0 to 400Hz, 9999 0.01Hz 9999 62
33 Frequency jump 2A 0 to 400Hz, 9999 0.01Hz 9999 62
34 Frequency jump 2B 0 to 400Hz, 9999 0.01Hz 9999 62
35 Frequency jump 3A 0 to 400Hz, 9999 0.01Hz 9999 62
36 Frequency jump 3B 0 to 400Hz, 9999 0.01Hz 9999 62
St
andard operat
ion f
unc
tions
37 Speed display 0,1 to 9998 1 0 63
41 Up-to-frequency sensitivity 0 to 100% 0.1% 10% 64
42 Output frequency detection 0 to 400Hz 0.01Hz 6Hz 64
Out
put
te
rm
inal
func
tions
43
Output frequency detection for reverse
rotation
0 to 400Hz, 9999 0.01Hz 9999 64
44 Second acceleration/deceleration time
0 to 3600 sec/
0 to 360 sec
0.1 sec/
0.01 sec
5 sec 65
45 Second deceleration time
0 to 3600 sec/
0 to 360 sec, 9999
0.1 sec/
0.01 sec
9999 65
46 Second torque boost (Note 1) 0 to 30%, 9999 0.1% 9999 65
47 Second V/F (base frequency) (Note 1) 0 to 400Hz, 9999 0.01Hz 9999 65
*48 Second stall prevention operation current 0 to 150% 0.1% 150% 65
49
Second stall prevention operation
frequency
0 to 400Hz, 9999 0.01Hz 0 65
Sec
ond f
unc
tions
50 Second output frequency detection 0 to 400Hz 0.01Hz 30Hz 64
