G0646/G0647 50/65 Ton Ironworker
-65-
G0646 Cabinet
REF PART # DESCRIPTION REF PART # DESCRIPTION
5 P0646005 FRONT ACCESS PANEL 190 P0646190 FOOT PEDAL
6 P0646006 SUB-PANEL 190-1 P0646190-1 FOOT PEDAL FLEXIBLE CONDUIT
7 P0646007 REAR ACCESS PANEL 190-2 P0646190-2 FOOT PEDAL ELECTRICAL CABLE
8 P0646008 LIMIT SWITCH ACCESS PANEL 191 P0646191 EMERGENCY STOP BUTTON
88 PB04M HEX BOLT M6-1 X 10 191-1 P0646191-1 EMERGENCY STOP BUTTON BOX
89 PW03M FLAT WASHER 6MM 194 P0646194 ELECTRICAL CABINET
153 P0646153 RAM LIMIT SWITCH 194-1 P0646194-1 CABINET DOOR
168 P0646168 HYDRAULIC CYLINDER 195 P0646195 ROTARY SWITCH
169 P0646169 RAM 196 P0646196 DOOR LOCK
173 P0646173 HYD. LINE MANIFOLD-CYLINDER 197 P0646197 DOOR LOCK KEY PLASTIC
174 P0646174 HYD. LINE MANIFOLD-CYLINDER 198 P0646198 POWER LAMP
175 P0646175 HYD. LINE PUMP-MANIFOLD 199 P0646199 EMERGENCY STOP BUTTON
176 P0646176 HYD. LINE TANK-PUMP 200 P0646200 MOTOR START BUTTON
177 P0646177 HYDRAULIC MANIFOLD 201 P0646201 NORMAL/INCH SWITCH
178 P0646178 OIL CATCH PAN 202 P0646202 MOTOR STOP BUTTON
179 P0646179 HYDRAULIC CONTROL VALVE ASSY 203 P0646203 PUNCH/NOTCH SWITCH
180 P0646180 HYDRAULIC VALVE SOLENOID 204 P0646204 BASE
181 P0646181 HYDRAULIC RESERVOIR 205 PN01M HEX NUT M6-1
181-1 P0646181-1 RESERVOIR ACCESS PANEL 207 P0646207 MAIN POWER SWITCH
181-2 PB04M HEX BOLT M6-1 X 10 208 P0646208 CONTACTOR TECO 16-N 220/440V
181-3 P0646181-3 RES. ACCESS PANEL GASKET 208-1 P0646208-1 CONTACTOR TECO CNA-2 220/440V
182 P0646182 OIL SIGHT GLASS & THERMOMETER 209 P0646209 OL RELAY TECO RHN-10K 12.5-18
183 P0646183 MOTOR 5HP 220/440V 3-PH 209-1 P0646209-1 OL RELAY TECO RHN10K 7-11
183-1 P0646183-1 MOTOR FAN COVER 210 P0646210 FUSE ASSEMBLY 5A
183-2 P0646183-2 MOTOR FAN 211 P0646211 ELECTRICAL COMMUTATOR
183-3 P0646183-3 MOTOR JUNCTION BOX 212 P0646212 TRANSFORMER
184 P0646184 HYDRAULIC PUMP 213 P0646213 TERMINAL BLOCK
185 P0646185 FILLER CAP 213-1 P0646213-1 ELECTRICAL PANEL
185-1 P0646185-1 FILLER SCREEN 213-2 P0646213-2 STRAIN RELIEF LARGE
185-2 P0646185-2 FILLER CAP GASKET 213-3 P0646213-3 STRAIN RELIEF SMALL
