G0646/G0647 50/65 Ton Ironworker
-59-
G0646 Upper Front-Half Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
11 P0646011 PIVOT SHAFT 66 PW06M FLAT WASHER 12MM
12 P0646012 LOCK PLATE 67 PN09M HEX NUT M12-1.75
13 PSB61M CAP SCREW M10-1.5 X 20 70 P0646070 PUNCH TABLE
14 P0646014 PIVOT SHAFT BUSHING 71 PFH61M FLAT HD CAP SCR M12-1.75 X 35
15 P0646015 HEX BOLT M20-2.5 X 140 72 P0646072 PUNCH TABLE EXTENSION
18 P0646018 SET SCREW M24-3 X 50 73 PFH62M FLAT HD CAP SCR M12-1.75 X 20
19 PN44M HEX NUT M24-3 74 P0646074 SHEAR TABLE
21 P0646021 HEX BOLT M24-3 X 65 75 PFH63M FLAT HD CAP SCR M12-1.75 X 25
22 PN44M HEX NUT M24-3 79 P0646079 TABLE GUIDE
23 P0646023 LEAD SCREW NUT 81 P0646081 LOCK HANDLE 1/2-13
24 PW03M FLAT WASHER 6MM 82 PW01 FLAT WASHER 1/2
25 PSB07M CAP SCREW M6-1 X 30 83 PCB32M CARRIAGE BOLT 1/2-13 X 1-3/4
26 P0646026 HOLD-DOWN UPPER 90 P0646090 MOUNTING BLOCK
27 P0646027 SECTION FRAME 91 PSB54M CAP SCREW M16-2 X 40
28 P0646028 HOLD-DOWN LOWER 92 PLW10M LOCK WASHER 16MM
29 P0646029 HANDWHEEL 93 P0646093 PUNCH SIDE GUARD
30 P0646030 STAR KNOB M16-2 X 30 94 PB04M HEX BOLT M6-1 X 10
31 PW08M FLAT WASHER 16MM 95 PW03M FLAT WASHER 6MM
32 PSB36M CAP SCREW M12-1.75 X 25 96 P0646096 PUNCH GUARD PLEXIGLASS
33 PW06M FLAT WASHER 12MM 97 PW03M FLAT WASHER 6MM
34 P0646034 SUPPORT PLATE 98 PB04M HEX BOLT M6-1 X 10
35 PSB61M CAP SCREW M10-1.5 X 20 99 P0646099 PUNCH TABLE CONNECTING PLATE
36 PW04M FLAT WASHER 10MM 100 PW06M FLAT WASHER 12MM
37 P0646037 ANGLE HOLD-DOWN BOLT LONG 101 PN09M HEX NUT M12-1.75
38 P0646038 ANGLE HOLD-DOWN BOLT SHORT 131 P0646131 NOTCH STRIPPER PLATE
39 P0646039 KNURLED LOCK RING 132 PLW10M LOCK WASHER 16MM
40 P0646040 UPPER HOLD-DOWN LEAD SCREW 133 PSB166M CAP SCREW M16-2 X 30
41 P0646041 BEVEL GEAR LARGE 150 P0646150 MOUNTING PLATE
41-1 P0646041-1 BEVEL GEAR SMALL 151 PSB167M CAP SCREW M6-1 X 70
42 P0646042 SPECIAL HEX NUT 152 PW03M FLAT WASHER 6MM
43 PSS01M SET SCREW M6-1 X 10 154 PW05M FLAT WASHER 4MM
44 PB47M HEX BOLT M6-1 X 40 155 PS51M PHLP HD SCR M4-.7 X 30
45 P0646045 BUSHING 157 PN04M HEX NUT M4-.7
46 P0646046 LOWER HOLD-DOWN ADJUST ROD 158 P0646158 SPACER 6MM
47 P0646047 SECTION BLADE CLAMP 159 P0646159 SPACER 8MM
48 PLW05M LOCK WASHER 12MM 160 P0646160 LIMIT STOP BRACKET
49 PSB77M CAP SCREW M12-1.75 X 30 161 PSB60M CAP SCREW M8-1.25 X 55
50 PN09M HEX NUT M12-1.75 162 P0646162 LIMIT STOP ASSEMBLY
51 PSS104M SET SCREW M12-1.75 X 45 163 PSS16M SET SCREW M8-1.25 X 10
54 PSB111M CAP SCREW M12-1.75 X 35 164 P0646164 HEX BOLT M12-1.75 X 150
55 PSS10M SET SCREW M10-1.5 X 20 165 PW06M FLAT WASHER 12MM
62 PSS10M SET SCREW M10-1.5 X 20 166 P0646166 LOCK COLLAR
65 PLW05M LOCK WASHER 12MM 167 PN09M HEX NUT M12-1.75
