-62-
G0646/G0647 50/65 Ton Ironworker
G0646 Upper Rear-Half Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 P0646001 TOP PANEL FRONT 81 P0646081 LOCK HANDLE 1/2-13
2 P0646002 TOP PANEL REAR 82 PW01 FLAT WASHER 1/2
3 P0646003 HANGER FRAME 83 PCB32M CARRIAGE BOLT 1/2-13 X 1-3/4
4 P0646004 TOP COVER 84 P0646084 SECTION REAR COVER
9 P0646009 LIFTING EYE BOLT MOUNT 85 P0646085 ANGLE REAR COVER
10 P0646010 LIFTING EYE BOLT 86 P0646086 SHEAR REAR COVER
16 PN28M HEX NUT M20-2.5 87 P0646087 SHEAR BOTTOM COVER
17 P0646017 HEX BOLT M20-2.5 X 125 88 PB04M HEX BOLT M6-1 X 10
20 P0646020 PRESSURE PAD 89 PW03M FLAT WASHER 6MM
52 P0646052 SECTION BLADE ARM 90 P0646090 MOUNTING BLOCK
53 P0646053 SECTION BLADE BODY 91 PSB54M CAP SCREW M16-2 X 40
56 PSB92M CAP SCREW M12-1.75 X 40 92 PLW10M LOCK WASHER 16MM
57 PLW05M LOCK WASHER 12MM 131 P0646131 NOTCH SIDE PLATE
58 P0646058 ANGLE BLADE BODY UPPER 132 PLW10M LOCK WASHER 16MM
59 P0646059 ANGLE BLADE BODY LOWER 133 PSB166M CAP SCREW M16-2 X 30
60 P0646060 ANGLE BLADE ARM LOWER 134 P0646134 NOTCH END GUARD
61 P0646061 ANGLE BLADE ARM UPPER 135 PB04M HEX BOLT M6-1 X 10
63 PFH64M FLAT HD CAP SCR M10-1.5 X 60 136 PW03M FLAT WASHER 6MM
64 PFH65M FLAT HD CAP SCR M10-1.5 X 55 170 P0646170 BUSHING
65 PLW05M LOCK WASHER 12MM 171 P0646171 CYLINDER AXLE
67 PN09M HEX NUT M12-1.75 172 P0646172 SPECIAL EXT RETAINING RING
68 P0646068 SHEAR BLADE ARM 186 PSB50M CAP SCREW M5-.8 X 10
69 P0646069 SHEAR BLADE BODY 187 P0646187 OIL LINE ELBOW CONNECTOR 4MM
76 P0646076 NOTCH TABLE 188 P0646188 OIL LINE 4-WAY CONNECTOR 4MM
77 PFH66M FLAT HD CAP SCR M10-1.5 X 30 189 P0646189 OIL LINE 4MM
78 PFH67M FLAT HD CAP SCR M8-1.25 X 25 189-1 P0646189-1 ONE-SHOT OILER
79 P0646079 TABLE GUIDE
