G0646/G0647 50/65 Ton Ironworker
-63-
G0647 Upper Rear-Half Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 P0647001 TOP PANEL FRONT 81 P0647081 LOCK HANDLE 1/2-13
2 P0647002 TOP PANEL REAR 82 PW01 FLAT WASHER 1/2
3 P0647003 HANGER FRAME 83 PCB32M CARRIAGE BOLT 1/2-13 X 1-3/4
4 P0647004 TOP COVER 84 P0647084 SECTION REAR COVER
9 P0647009 LIFTING EYE BOLT MOUNT 85 P0647085 ANGLE REAR COVER
10 P0646010 LIFTING EYE BOLT 86 P0647086 SHEAR REAR COVER
16 PN28M HEX NUT M20-2.5 87 P0647087 SHEAR BOTTOM COVER
17 P0646017 HEX BOLT M20-2.5 X 125 88 PB04M HEX BOLT M6-1 X 10
20 P0647020 PRESSURE PAD 89 PW03M FLAT WASHER 6MM
52 P0647052 SECTION BLADE ARM 90 P0647090 MOUNTING BLOCK
53 P0647053 SECTION BLADE BODY 91 PSB54M CAP SCREW M16-2 X 40
56 PSB92M CAP SCREW M12-1.75 X 40 92 PLW10M LOCK WASHER 16MM
57 PLW05M LOCK WASHER 12MM 131 P0647131 NOTCH SIDE PLATE
58 P0647058 ANGLE BLADE BODY UPPER 132 PLW10M LOCK WASHER 16MM
59 P0647059 ANGLE BLADE BODY LOWER 133 PSB166M CAP SCREW M16-2 X 30
60 P0647060 ANGLE BLADE ARM LOWER 134 P0647134 NOTCH END GUARD
61 P0647061 ANGLE BLADE ARM UPPER 135 PB04M HEX BOLT M6-1 X 10
63 PFH64M FLAT HD CAP SCR M10-1.5 X 60 136 PW03M FLAT WASHER 6MM
64 PFH65M FLAT HD CAP SCR M10-1.5 X 55 170 P0647170 BUSHING
65 PLW05M LOCK WASHER 12MM 171 P0647171 CYLINDER AXLE
67 PN09M HEX NUT M12-1.75 172 P0647172 SPECIAL EXT RETAINING RING
68 P0647068 SHEAR BLADE ARM 186 PSB50M CAP SCREW M5-.8 X 10
69 P0647069 SHEAR BLADE BODY 187 P0646187 OIL LINE ELBOW CONNECTOR 4MM
76 P0647076 NOTCH TABLE 188 P0646188 OIL LINE 4-WAY CONNECTOR 4MM
77 PFH66M FLAT HD CAP SCR M10-1.5 X 30 189 P0646189 OIL LINE 4MM
78 PFH67M FLAT HD CAP SCR M8-1.25 X 25 189-1 P0646189-1 ONE-SHOT OILER
79 P0647079 TABLE GUIDE
