61
Installing PCI expansion cards
www.gateway.com
4
Locate the appropriate riser card, then lift the riser card from the system
board by lifting the blue plastic loop and the end of the riser card closest
to the front of the server.
5
Pull the card locking clip open, then swing the locking clip away from the
riser card.
6
If you are replacing a card, remove the old expansion card. You can slightly
seesaw the card end-to-end to loosen the card, but do not bend the card
sideways.
Warning Do not touch the contacts on the bottom part of the
expansion card. Touching the contacts can cause
electrostatic damage to the card.
