ADAC Ultra2 S466 Hardware Guide 34
ADAC Ultra2 S466 Specifications
Parameter Specification
Card Size 7.375" x 4.2" (half length PCI)
Processor Intel i960RP™ 32-bit RISC processor @ 33 MHz
Bus Type PCI 2.1
PCI Controller Intel i960RP
Bus Data Transfer Rate Up to 132 MB/s
BIOS AMIBIOS ADAC Ultra2 S466 BIOS
Cache Configuration 4, 8, 16, 32, 64, or 128 MB through a 60 ns × 36
Fast Page Mode or EDO 72-pin SIMM.
Firmware 1 MB × 8 flash ROM
Nonvolatile RAM 32 KB × 8 for storing RAID configuration
Operating Voltage 5.00 V ± 0.25 V
SCSI Controller One SCSI controller for Ultra and Wide support.
SCSI Data Transfer
Rate
Up to 80 MB/s
SCSI Bus LVD or single-ended
SCSI Termination Active
Termination Disable Automatic through cable and device detection
Devices per SCSI
Channel
Up to 15 wide or seven non-wide SCSI devices. Up
to 6 non-disk SCSI drives per ADAC Ultra2 S466
controller.
SCSI Device Types
Supported
Synchronous or Asynchronous. Disk and non-disk.
RAID Levels Supported 0, 1, 3, 5,10, 30, and 50
SCSI Connectors One 68-pin internal high-density connector for 16-
bit SCSI devices. One ultra-high density 68-pin
external connector for Ultra and Wide SCSI.
Serial Port 9-pin RS232C-compatible berg
