Replacing the control panel board 75
Replacing the control panel board
The control panel board is mounted on the front of the chassis, behind the
bezel.
To replace the control panel board:
1 Turn off the system and disconnect the power cord, modem cord (if
installed), and all external peripheral devices.
2 Observe all safety and static electricity precautions. (See “Preventing static
electricity discharge” on page 22.)
3 Remove the bezel. (See “Removing the bezel” on page 25.)
4 Remove the left side cover panel. (See “Removing the side cover panel”
on page 26.)
5 Disconnect the front panel connector from the control panel board.
6 Remove the screw that secures the board to the front of the chassis.
7 Lift the control panel board off of the hooks on the front panel, then
remove it.
