Front side – Gateway 7400 User Manual
Page 19
SCSI backplane board
11
Front side
Reserved LED (6) reserved for future use.
Drive activity LED (6) flashes green when the drive is actively reading or
writing data.
SCA SCSI drive connectors (6) provide points of connection for six SCA SCSI
drives.
Drive activity LED (6)
Reserved LED (6)
SCA SCSI drive connectors (6)
SCSI ID 0
SCSI ID 1
SCSI ID 2
SCSI ID 3
SCSI ID 4
SCSI ID 5
8508366.book Page 11 Tuesday, October 23, 2001 11:29 AM
