4. ECHO SOUNDER MODE
4-3
4.3 Choosing a Range
The RANGE control chooses the detection (display) range, in 15 settings. Choose the
range according to either the fish species being searched or the depth desired. Each time
the control is operated the newly chosen range briefly appears in large characters at the
screen top. Range is permanently displayed at the top right-hand corner.
Normally the range is set so that the bottom is traced at the lower part of the screen.
Surface
Bottom
RANGE m
Range concept
Default echo sounder mode range settings
Unit 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
Meters
10 20 30 40 60 80 100 120 160 200 250 300 400 500 600
Feet 30 60 90 120 150 200 250 300 400 500 600 800 1000 1500 2000
Note 1:
Unit of range measurement may be selected for meters, feet, fathoms, passi/braza
or Hiro (Japanese). For details see UNIT on page 5-11.
Note 2:
Ranges may be freely preset as desired. For details see page 5-16.
