FURUNO
CH-300
SP - 3 E125S01A
4.6 Vertical Scan Mode Control
Scanning angle: 6
° to 180°, 12° step
Scanning center: 0
° to 180°, 6° step
Scanning step angle: Normal: 3
°, High speed: 6°
Time to train: 360
°, 6° step
4.7 Transceiver Beam Width Frequency Horizontal Vertical
60 kHz: 16
°/22°
14
°/20°
85 kHz: 11
°/15°
10
°/14°
153 kHz: 7
°/9°
5
°/8°
215 kHz: 5
°/6°
4
°/6°
4.8 Allowable Ship’s Speed 20 knot or less (15 knot during raise/lower operation)
4.9 Stabilization Within 30
°, optional motion sensor required
5. I/O INTERFACE
5.1 Data Format IEC61162-1 (NMEA0183 Ver 1.5/2.0)
5.2 Input DBS, DBT, DPT, GGA, GLL, HDG, HDM, HDT, MDA, MTW, RMA,
RMC, VDR, VHW, VTG, att (P sentence)
5.3 Output SSTLL
6 POWER SUPPLY
6.1 MU-100C/Control Unit, Transceiver Unit
12-24 VDC: 7.0-3.5A
6.2 Control Unit, Transceiver Unit
12-24 VDC: 5.0-2.5A
6.3 Hull Unit 12/24 VDC: 4.7/2.3A (16.7/8.2-A, during raising and lowering)
7. ENVIRONMENTAL CONDITIONS
7.1 Ambient Temperature -15°C to +55°C (Soundome: 0°C to +35°C)
7.2 Relative Humidity Less than 95%
7.3 Waterproofing Control unit: IPX5
Transceiver unit: IPX0
Hull unit: IPX2
MU-100C: IPX5
7.4 Vibration 2 Hz-5Hz to 13.2 Hz: Amplitude: ±1 mm ±10%
13.2 Hz to 100 Hz: Max. acceleration 7m/s
2
, fixed
8. COATING COLOR
8.1 Control Unit Panel: N3.0, Chassis: 2.5GY5/1.5
8.2 Transceiver Unit 2.5GY5/1.5
8.3 MU-100C Panel: N3.0 Newtone No.5, Chassis: 2.5GY5/1.5
