5. MENU OPERATION
5-16
5.4.5 Echo sounder mode range settings
As with the horizontal and vertical scan modes, the user may preset the echo sounder
mode’s ranges.
1. Choose RANGE-E/S MODE at the SYS menu and then press ►.
2 : 20
3 : 30
4 : 40
10 : 200
11 : 250
12 : 300
13 : 400
14 : 500
15 : 600
DEFAULT SETTING : NO YES
: SELECT : CHANGE MENU: END
1 : 10 (10-600m)
5 : 60
6 : 80
7 : 100
8 : 120
9 : 160
** RANGE-E/S MODE **
Range-E/S mode dialog box
2. Press ▲ or ▼ to choose range number desired.
3. Press ◄ or ► to set range. The setting range depends on the transducer used.
4. To restore default echo sounder mode range settings, choose DEFAULT SETTING,
press ► to choose YES and press the MENU key.
5. Press the MENU key to register settings and close the menu.
