1.8.3 MEMORY POPULATION RULES
1. Suppor ts only SDRAM DIMM.
2. To operate properly, at least one 168-pin DIMM module must be in-stalled.
3. This mainboard suppor ts Table Free memor y, so memor y can be installed on
DIMM1 or DIMM 2 in any order.
4. Suppor ts 3.3 volt DIMM.
5. The DRAM addressing and the size supported by the mainboard is shown
below:
Table 1-2 SDRAM Memor y Addressing
DRAM
Tech.
16M
64M
64M
DRAM
Density & Width
1Mx16
2Mx8
2Mx32
2Mx32
4Mx16
4Mx16
8Mx8
2Mx32
4Mx16
8Mx8
DRAM
Addressing
ASYM
ASYM
ASYM
ASYM
ASYM
ASYM
ASYM
ASYM
ASYM
ASYM
Row Column
11 8
11 9
11 9
12 8
11 10
13 8
13 9
11 8
12 8
12 9
Single
Side(S) Double
Side(D)
MB/DIMM Address Size
8MBx4 16MBx8
16MBx8 32MBx16
32MBx2 64MBx4
16MBx2 32MBx4
32MB 64MB
32MB 64MB
64MB 128MB
16MB 32MB
--- ---
--- ---
no.
pcs.
no.
pcs.
