18
1.8.2 MEMORY INSTALLATION PROCEDURES
A. How to install a DIMM Module
Double Sided DIMM
1. The DIMM slot has 2 Notch Keys “VOLT and DRAM”, so the DIMM memory
module can only fit in one direction.
2. Inser t the DIMM memory module ver tically into the DIMM slot. Then push it in.
VOLT DRAM
3. The plastic clip at the side of the DIMM slot will automatically close.
Single Sided DIMM
