5 Virtual-IO Manager user interface

Fabric 3

All paths are routed to fabric 3.

Fabric 4

All paths are routed to fabric 4.

Fabric 3 & 4

LAN1 is routed to fabric 3 and LAN2 to fabric 4.

For more information on SMUX settings, see the documentation "PRIM-
ERGY BX900 Blade Server Systems - ServerView Management Blade
S1".

The upper table displays the onboard ports (up to 6). Another table is dis-
played for each available mezzanine/PCI card configured in the previous
step. The tables have the following columns:

Column Significance

first col-
umn

Port number of the onboard or the mezzanine/PCI card port. On
CNA cards the type of the function (LAN, FCoE, iSCSI) can be
selected from the drop-down list.

Another function can be added to this port with the

button.

Functions can be removed with the

button.
