Chapter 4 theory of device operation – FUJITSU MHV2160BT User Manual
Page 57
C141-E239
4-1
CHAPTER 4 Theory of Device Operation
4.1 Outline
4.2 Subassemblies
4.3 Circuit
Configuration
4.4 Power-on
Sequence
4.5 Self-calibration
4.6 Read/write
Circuit
4.7 Servo
Control
This chapter explains basic design concepts of the disk drive. Also, this chapter
explains subassemblies of the disk drive, each sequence, servo control, and
electrical circuit blocks.
