Table 5.25 Format of SCT STATUS Response (1/2)
BYTE Contents
000h
001h
Format Version
002h
003h
SCT Version
004h
005h
SCT Spec
006h
007h
008h
009h
Status Flag
Bit31-1: Reserved
Bit0: Initialized flag (maintained Power-OFF/ON)
0 = After it had made it to initial of not initializing by data pattern in
which all LBA was defined by the LBA SEGMENT ACCESS
command (action code 0x0002) or write after it had initialized.
This bit is also cleared if the capacity of the drive is changed via
SET MAX (EXT), DCO.
1= It initialized it by data pattern in which all LBA was defined by the
LBA SEGMENT ACCESS command (action code 0x0002).
00Ah
Drive State
00h = Active
01h = not support (Standby)
02h = not support (Sleep)
03h = DST executing in background.
04h = SMART Off-line Data collection executing in background.
05h = SCT command executing in background.
06h-FFh = Reserved
00Bh
to
00Dh
Reserved
00Eh
00Fh
Extended Status Code
Status of last SCT command issued.
* (See Table 5.26)
010h
011h
Action Code
Action code of last SCT command issued.
012h
013h
Function Code
Function code of last SCT command issued.
