3.2 Mounting
C141-E239
3-3
3.2 Mounting
For information on mounting, see the "FUJITSU 2.5-INCH HDD
INTEGRATION GUIDANCE (C141-E144)."
(1) Orientation
Figure 3.2 illustrates the allowable orientations for the disk drive.
(a) Horizontal –1
(b) Horizontal –2
(c) Vertical –1
(d) Vertical –2
gravity
gravity
(e) Vertical –3
(f) Vertical –4
gravity
Figure 3.2 Orientation
