FUJITSU MHV2160BT User Manual
Page 167

5.3 Host Commands
C141-E239
5-91
Host
Reg. HD
PIO Setup
PIO Setup
PIO Setup
Data (1sector)
Data
(4 sectors)
Device
Data
(4 sectors)
Block
Block
Partial
Block
Figure 5.12 Execution example of READ MULTIPLE command
•
Error reporting conditions
(1) A specified address exceeds the range where read operations are allowed
(ST = 51h, ER = 10h).
(2) The range where read operations are allowed will be exceeded by an address
during a read operation (ST = 51h, ER = 10h).
(3) An uncorrectable disk read error occurred (ST = 51h, ER = 40h).
(4) The sync byte indicating the beginning of a sector was not found
(ST = 51h, ER = 01h).
(5) The READ MULTIPLE command is disabled (ST = 51h, ER = 04h).
(6) A SATA communication error occurred (ST = 51h, ER = 0Ch).
(7) An error other than the above errors occurred (ST = 51h, ER = 04h).
