5.3 Host Commands
C141-E239 5-83
• SCT READ DATA (SN = E1h, FR = D5)
This command reads the data specified with SCT SET COMMAND and number
of sectors specified Sector Count field
28-bit command
At command issuance (Shadow Block Registers setting)
CM 1 0 1 1 0 0 0 0
DH x x x DV Xx
CH
CL
SN
SC
FR
Key (C2h)
Key (4Fh)
E1h
xx
D5h
At command completion (Shadow Block Registers contents to be read)
ST Status information
DH x x x DV xx
CH
CL
SN
SC
ER
xx
xx
xx
xx
Error information
SCT READ DATA Command issue procedure.
1. Issue the SCT set command of action code 0005h.
2. Issue the SCT READ DATA command and receive the HDA temperature
data from the device.
