3 connections with host system, 1 device connector – FUJITSU MHV2160BT User Manual
Page 53
3.3 Connections with Host System
C141-E239
3-9
3.3 Connections with Host System
3.3.1 Device connector
The disk drive has the SATA interface connectors listed below for connecting
external devices. Figure 3.8 shows the locations of these connectors and
terminals.
SATA interface
and power
connectors
PCA
Figure 3.8 Connector locations
