3.3 Connections with Host System

C141-E239

3-11

3.3.4 SATA interface cable connection

The cable that connects the disk drive to the host system must be compliant with
the Serial ATA 1.0a specification.

3.3.5 Note about SATA interface cable connection

Take note of the following precaution about plugging a SATA interface cable into
the SATA interface connector of the disk drive and plugging the connector into a
host receptacle:

When plugging together the disk drive SATA interface connector
and the host receptacle or SATA interface cable connector, do not
apply more than 10 kgf of force in the connection direction once
they are snugly and securely in position.
