PREPARATION ▸ CHARGING THE BATTERY 29
CHARGING THE BATTERY
The camera is powered by a lithium-ion battery.
INSERTING THE BATTERY IN THE CHARGER
▸ Slide the battery into the charger with the grooves facing down
until the contacts meet
▸ Press down on the battery until you can hear and feel it clicking
into place
▸ Ensure that the battery is fully inserted into the charger
REMOVING THE BATTERY FROM THE CHARGER
▸ Pull the rechargeable battery up and out
CHARGE STATUS INDICATORS ON THE CHARGER
The status LED indicates a correct charging process.
Display Charge status Charge time*
CHARGE flashes green Battery is charging
80% lights up orange 80% Approx. 2 h
CHARGE continuous
green light
100% Approx. 3.5 h
Disconnect the charger from mains electricity when the charging
process is complete. There is no risk of overcharging.
* starting from a discharged state
