Installation
28
Connect to audio equipment
External audio devices
Audio cable
(Stereo)
Audio IN
Audio output
Audio cable
(Stereo)
Audio output
Audio input
(R)
(R)
(L)
(L)
Audio
cable
Note
The left and right
channels are
combined when
only the L (Mono)
is inserted.
• For IN1029, IN1039, IN1049, IN1059, IN1024, IN1034, IN1044, IN1026,
IN1036, IN1046
Cables for connection:
• Audio cable*
* This cable is not included
Audio output
Audio IN
(R) (L)
Audio IN
Audio output
(R) (L)
