Page 53

Chapter 4

Operation

Selecting and controlling a DVMRe/multiplexer

When a zone is active, the corresponding DVMRe/multiplexer can be controlled by the keypad (Table 5).

Table 5.

Controlling a multiplexer

Control

Function for multiplexer

Function for DVMRe

starts record mode

starts playback mode (if multiplexer has an attached
DSR/VCR, a play command is sent to the multiplexer
and the VCR)

starts playback mode

stops playback or record mode

pauses live picture; pauses playback

pauses playback or live view

toggles image between normal and 2X magnification
(joystick moves view)

zooms image to 2X magnification (toggle)

calls up screen to search for specific recording
puts DVMRe in playback mode

Joystick

when attached to a DSR/VCR in pause mode
twisting right: steps forward at a variable rate
twisting left: steps in reverse at a variable rate

in any mode with 2X magnification
right: pans right
left: pans left
up: pans up
down: pans down

in play or pause mode
right: fast forwards
left: rewinds
up: skips forward approximately 15 sec
down: skips backward approximately 15 sec
twisting right: steps forward at a variable rate
twisting left: steps in reverse at a variable rate
return to center: resumes pause mode
with 2X magnification on
right: pans right
left: pans left
up: pans up
down: pans down

fast forwards playback

rewinds playback

in pause mode, steps forward one frame

in reverse: shifts play direction to forward
in pause mode: steps playback forward one frame

in pause mode, steps in reverse one frame

playing forward: shifts play direction to reverse
in pause mode: steps playback in reverse one frame
