Industrial Data Systems IDS DT220 - Manual (Page 32)

DT220 Users Manual version 1.a Configuration Parameters
28
210 Time\date Time and Date
211 Time Time
212 Date Date
213 Stime Stored time
214 Sdate Stored date
255 Exit Setpoint always trips
Print Format Design Example
EXAMPLE PRINT:
EXAMPLE FORMAT DESIGN WORKSHEET:
Page:1 Item Description Line No. Column Item No.
E1 Gross Weight 3 4 91
E2 Tare Weight 4 4 92
E3 Net Weight 5 4 93
E4 Time and Date 7 1 210
E5 End of Print 0 0 0
NOTE: A zero in the Line No column terminates printing. Use zero only after all
required information has been entered. The maximum number of entries is 16.
If the 16 th entry is used, a line number 0 is not required.
Default Print Formats
The print formats (PAGES) are initialized to the following factory settings when the
DT220 is initialized.
Page 1 Item Description Line No. Column Item No.
E1 Gross Weight 1 5 91
E2 Time and Date 2 5 210
E3 End of Print 0 0 0
1111111111222222222233333333334
COLUMN 1234567890123456789012345678901234567890
LINE
1
2
3 GROSS 54785 LB
4 TARE 12451 LB
5 NET 42243 LB
6
7 TIME 03:45 PM DATE 05 AUG 1999
