Pulsafeeder Digital Glycol Feeder DGF2 - Manual (Page 27)

22
Lead Color Connection of: Terminal Block
U.S. International
Inputs J14 Multiple Multiple
J34-1 COM Red Red
J34-2 N.O. Black Black Dry Contact #1 (Alarm Option)
J34-3 N.C. Black Black
J28-1 COM White White
J28-2 N.O. Black Black Dry Contact #2 (Alarm Option)
J28-3 N.C. Black Black
J34-2 N.O. Black Brown
J34-3 N.C. Black Brown
J34-4 Return White Blue
AC Output #1 (Alarm Option)
J34-5 Ground Green Green/Yellow Stripe
J28-2 N.O. Black Brown
J28-3 N.C. Black Brown
J28-4 Return White Blue
AC Output #2 (Alarm Option)
J28-5 Ground Green Green/Yellow Stripe
J6-3 N.O. Black Brown
J2-3 Return White Blue Pump #1
J3-3 Ground Green Green/Yellow Stripe
J7-3 N.O. Black Brown
J2-1 Return White Blue Pump #2
J3-1 Ground Green Green/Yellow Stripe
Audible Alarm + J5 Red Red
Audible Alarm – J6 Black Black
J4-1 Hot Black Brown
J4-2 Return White Blue
Power Cord or Conduit Wiring
“Non-CE “ Units
J4-3 Ground Green Green/Yellow Stripe
Line Filter Hot N/A Brown
Line Filter Return N/A Blue
Power Cord or Conduit Wiring
“CE “ Units
Line Filter Ground N/A Green/Yellow Stripe
