CAL SPECIFICATION FILES TECHNICAL DETAILS
ME7840A OMM A-9
4. harm (Harmonics):
Header Section Keywords:
ncal Number of calibration sequences of this type to run.
if IF bandwidth: Legal values are 10, 30, 100, 300, 1000, 3000, 10000, 30000
avgs Averages: (Optional). Software will set averaging to value (and turn on) during cal.
pow Start power level for sweep: Set on for Source 1.
switch Setting for test set. Correponds to 0 - 15 settings.
Detail Section Keywords:
CAL, 1 First calibration
name Name of *.cal file to save when calibration sequence completes.
f1 Main tone, MHz
f2 Maximum display range, MHz
NOTE: Minumum display range is automatically set to 100 MHz.
Example Refer to Figure A-2 (page A-12).
Table A-1. Technical Details of Calibration Specification Files (8 of 9).
Header
HARM_START
HARM_END
Details
