2.10. Technical specification of Binary input and output
Port IO
Binary input reed contact
with trigger level 1,3
up to 1,4 V Input/Output
Binary output 120 mA/max. 30 V
2.11. Modem status indication
On the front and back panel of the modem there are altogether eight LED indicators,
which inform on the modem status. On every port are two LED indicators, which inform port
status.
Panel Color Description Description
Front Green PWR
Blinking ......................... router is ready
Permanently on ………..starting of the router
Front Red GSM Blinking ……….. communication in progress
Front Yellow PPP On......................join PPP connection
Front Yellow USR Function selected by user
Front Green OUT On.......................Binary output active
Front Green IN On...................... Binary input active
Front Green ETH
On ...................... selected 100 Mbit/s
Off ...................... selected 10 Mbit/s
Front Yellow ETH
On........................ the network cable is connected
Blinking ……….... data transmission
Off ....................... the network cable is not connected
Front Green PORT Description by port (viz. Technical specification)
Front Yellow PORT Description by port (viz. Technical specification)
Front Yellow SIM1 On......................SIM card 1 is active
Front Yellow SIM2 On......................SIM card 2 is active
