EXPANSION PORT MOUNTING
21
•
Expansion port ETHERNET
Expansion port ETH
Power supply Internal ....
Operating temperature -30 .. +60 °C Environment
Storage temperature -30 .. +85 °C
Emission EN 55022/B
Immunity ETS 300 342
Standards
Safety EN 60950
Max. bit rate 100 Mbps Ethernet
(IEEE 802.3)
Max. total cable length
(300Bd, 200nF/km) 100 m
LED port indicator
Green LED On ...................... selected 100 Mbit/s
Off ...................... selected 10 Mbit/s
Yellow LED On........................ the network cable is connected
Blinking ……….... data transmission
Off ....................... the network cable is not connected
•
Expansion port M-BUSD
Expansion port M-BUSD
Voltage +10 .. +30 V Power supply
Supply power Max. 4 W
Operating temperature -30 .. +60 °C Environment
Storage temperature -30 .. +85 °C
Emission EN 55022/B
Immunity ETS 300 342
Standards
Safety EN 60950
Max. devices (each 1,5 mA) 30
Max. operating bus current
60 mA
Overload detection 100 mA
Short circuit strength Permanent
Bus voltage mark 36 .. 43 V
Bus voltage space 24 .. 31 V
M-BUS specifications
(EN 1434)
Max. total cable length
(300Bd, 200nF/km) 1000 m
LED port indicator
Green LED Indicates Receive data
Yellow LED Indicates Transmit data
Both LED lights Indicates short circuit on the MBUS
